14.1.4.4. Unbounded 3D Diffusion Data Model Scripting Example

MCell and CellBlender can be easily used to demonstrate unbounded 3D diffusion. Simply release a large number of molecules at the origin and watch them diffuse. However, to make measurements, a little more work is required.

This example uses a script that builds a series of concentric counting shells centered at the origin. The shells are assigned a transparent surface class so the molecules can pass through them. Counting statements are added to count the number of molecules in each shell (the total within each sphere minus the total in the next inner sphere). This allows easy plotting of the final result.

The following animation gives a visual outline of this process:

../_images/unbounded_diffusion_800.gif

14.1.4.4.1. Unbounded Diffusion Construction Script

The following script builds the CellBlender model for this example from scratch. It will be discussed in more detail below. If you just want to run this demonstration, copy this entire script and paste it into a Blender text editing window. Then press the “Run Script” button at the bottom of the text editing window. That should build the model ready for CellBlender to run it. Each section will be discussed further below this script.

# Import cellblender to get the data model and project directory functions

import math
import cellblender as cb

# Get a copy of the data model and change directories to the project directory for any file I/O

dm = cb.get_data_model(geometry=True)
old_location = cb.cd_to_project()

# Print some information about the data model

print ( "###############################################################" )

print ( "Data Model Top Level Keys = " + str(dm.keys()) )
print ( "MCell Keys = " + str(dm['mcell'].keys()) )

print ( "###############################################################" )


# Define parameters and set default values (these will also be available as local variables in this script)
#  The format for each parameter is:   Name, Value, Units, Description
#    All values are given as strings!!!

pars = [
  # These control the geometry of the model
  ['n',    "3",       '#',   'Number of shells to sample'],
  ['dr',   "0.1",    'um',   'Delta Radius of each successive shell'],
  ['ss',   "2",       '#',   'Surface Smoothness of each shell'],
  # These describe the behavior of the model
  ['dc',    "1e-6",   'cm^2/sec',    'Diffusion Constant of Molecules'],
  ['nrel',  "1000",   'Count',       'Number of molecules to release'],
  # These control the simulation itself
  ['iters', "600",   '',      'Number of iterations to run'],
  ['seeds', "1",     '',      'Number of seeds to run'],
  ['dt',    "1e-6",  'sec',   'Time step for each iteration of the simulation'],
 ]

# Update local parameter list values from the existing data model with user-modified settings BEFORE regenerating it
dm_par_list = dm['mcell']['parameter_system']['model_parameters']
for dm_par in dm_par_list:
    print ( "Data Model Parameter " + dm_par['par_name'] + " = " + dm_par['par_expression'] )
    for p in pars:
        if dm_par['par_name'] == p[0]:
            # Update the local expression based on the parameter found in the incoming data model
            p[1] = dm_par['par_expression']
            p[2] = dm_par['par_units']
            p[3] = dm_par['par_description']

# Create the local variables from the updated values to use in this script
for p in pars:
    locals()[p[0]] = eval(p[1])

# Create the new mcell data model inside the existing data model (this deletes the previous mcell data model)
dm['mcell'] = { 'data_model_version' : "DM_2014_10_24_1638" }


# Restore the parameters that were either initialized from scratch or preserved from the previous data model
dm['mcell']['parameter_system'] = { 'model_parameters':[] }   # Parameters are currently unversioned
for p in pars:
    dm['mcell']['parameter_system']['model_parameters'].append ( { 'par_name':p[0], 'par_expression':p[1], 'par_units':p[2], 'par_description':p[3] } )



##################################
#   Geometry  Support  Classes   #
##################################

class point:

  def __init__ ( self, x, y, z ):
    self.x = x;
    self.y = y;
    self.z = z;


class face:

  def __init__ ( self, v1, v2, v3 ):
    self.verts = [];
    self.verts.append ( v1 );
    self.verts.append ( v2 );
    self.verts.append ( v3 );


class IcoSphere:

  # Builds an icosphere with recursion

  def __init__ ( self ):
    self.points = []
    self.faces = []

  def make_dm_object ( self, center_x=0, center_y=0, center_z=0 ):
    obj = {}
    obj['vertex_list'] = []
    obj['element_connections'] = []

    for p in self.points:
      obj['vertex_list'].append ( [ center_x+p.x, center_y+p.y, center_z+p.z ] )
    for f in self.faces:
      obj['element_connections'].append ( f.verts )

    return obj

  def add_normalized_vertex ( self, p ):
    # Normalize the point
    # Add to the list of points if it's not already in the list
    # Return an index to the new or existing point in the list

    l = math.sqrt ( (p.x * p.x) + (p.y * p.y) + (p.z * p.z) );
    pnorm = point ( p.x/l, p.y/l, p.z/l );

    # Check if it's already there
    index = -1;
    for pt in self.points:
      if (pt.x == pnorm.x) and (pt.y == pnorm.y) and (pt.z == pnorm.z):
        index = self.points.index(pt)
        break;

    if (index < 0):
      self.points.append ( pnorm );
      index = self.points.index ( pnorm );
      #print ( "Added vertex at " + str(index) );
    #else:
    #  print ( "Found vertex at " + str(index) );
    return (index);


  def __init__ ( self, recursion_level, scale_x=1.0, scale_y=1.0, scale_z=1.0 ):

    self.points = [];

    t = (1.0 + math.sqrt(5.0)) / 2.0;  # Approx 1.618033988749895

    # Create 12 verticies from the 3 perpendicular planes whose corners define an icosahedron

    self.add_normalized_vertex ( point (-1,  t,  0) );
    self.add_normalized_vertex ( point ( 1,  t,  0) );
    self.add_normalized_vertex ( point (-1, -t,  0) );
    self.add_normalized_vertex ( point ( 1, -t,  0) );

    self.add_normalized_vertex ( point ( 0, -1,  t) );
    self.add_normalized_vertex ( point ( 0,  1,  t) );
    self.add_normalized_vertex ( point ( 0, -1, -t) );
    self.add_normalized_vertex ( point ( 0,  1, -t) );

    self.add_normalized_vertex ( point ( t,  0, -1) );
    self.add_normalized_vertex ( point ( t,  0,  1) );
    self.add_normalized_vertex ( point (-t,  0, -1) );
    self.add_normalized_vertex ( point (-t,  0,  1) );


    # Rotate all points such that the resulting icosphere will be separable at the equator

    if (True):
      # A PI/6 rotation about z (transform x and y) gives an approximate equator in x-y plane
      angle = (math.pi / 2) - math.atan(1/t);
      # print ( "Rotating with angle = " + str(180 * angle / math.pi) );
      for p in self.points:
        newx = (math.cos(angle) * p.x) - (math.sin(angle) * p.z);
        newz = (math.sin(angle) * p.x) + (math.cos(angle) * p.z);
        p.x = newx;
        p.z = newz;

    # Build the original 20 faces for the Icosphere

    self.faces = []

    # Add 5 faces around point 0 (top)
    self.faces.append ( face (  0, 11,  5 ) );
    self.faces.append ( face (  0,  5,  1 ) );
    self.faces.append ( face (  0,  1,  7 ) );
    self.faces.append ( face (  0,  7, 10 ) );
    self.faces.append ( face (  0, 10, 11 ) );

    # Add 5 faces adjacent faces
    self.faces.append ( face (  1,  5,  9 ) );
    self.faces.append ( face (  5, 11,  4 ) );
    self.faces.append ( face ( 11, 10,  2 ) );
    self.faces.append ( face ( 10,  7,  6 ) );
    self.faces.append ( face (  7,  1,  8 ) );

    # Add 5 faces around point 3 (bottom)
    self.faces.append ( face (  3,  9,  4 ) );
    self.faces.append ( face (  3,  4,  2 ) );
    self.faces.append ( face (  3,  2,  6 ) );
    self.faces.append ( face (  3,  6,  8 ) );
    self.faces.append ( face (  3,  8,  9 ) );

    # Add 5 faces adjacent faces
    self.faces.append ( face (  4,  9,  5 ) );
    self.faces.append ( face (  2,  4, 11 ) );
    self.faces.append ( face (  6,  2, 10 ) );
    self.faces.append ( face (  8,  6,  7 ) );
    self.faces.append ( face (  9,  8,  1 ) );


    # Subdivide the faces as requested by the recursion_level argument
    old_points = None;
    old_faces = None;

    for rlevel in range(recursion_level):
      # System.out.println ( "\nRecursion Level = " + rlevel );
      # Save the old points and faces and build a new set for this recursion level
      old_points = self.points;
      old_faces = self.faces;
      self.points = []
      self.faces = []
      for f in old_faces:
        # Split this face into 4 more faces
        midpoint = point(0,0,0)
        potential_new_points = []
        for i in range(6):
          potential_new_points.append ( point(0,0,0) )
        for side in range(3):
          p1 = old_points[f.verts[side]];
          p2 = old_points[f.verts[(side+1)%3]];
          midpoint = point ( ((p1.x+p2.x)/2), ((p1.y+p2.y)/2), ((p1.z+p2.z)/2) );
          potential_new_points[2*side] = p1;
          potential_new_points[(2*side)+1] = midpoint;
        # Add the 4 new faces
        # Start with the verticies ... add them all since add_normalized_vertex() will remove duplicates
        vertex_indicies = []
        for i in range(6):
          vertex_indicies.append ( 0 )
        for i in range(6):
          vertex_indicies[i] = self.add_normalized_vertex ( potential_new_points[i] );
        # Now add the 4 new faces
        self.faces.append ( face ( vertex_indicies[0], vertex_indicies[1], vertex_indicies[5] ) );
        self.faces.append ( face ( vertex_indicies[1], vertex_indicies[2], vertex_indicies[3] ) );
        self.faces.append ( face ( vertex_indicies[3], vertex_indicies[4], vertex_indicies[5] ) );
        self.faces.append ( face ( vertex_indicies[1], vertex_indicies[3], vertex_indicies[5] ) );

    for pt in self.points:
      pt.x *= scale_x
      pt.y *= scale_y
      pt.z *= scale_z



# Add materials for the objects
dm['mcell']['materials'] = { 'material_dict' : {} }   # Materials are currently unversioned
dm['mcell']['materials']['material_dict']['shell_color']   = { 'diffuse_color' : {'a':0.3, 'r':0.2, 'g':0.4, 'b':1.0} }


# Create container objects for geometrical objects and model objects
dm['mcell']['geometrical_objects'] = {}   # Geometrical objects are currently unversioned
dm['mcell']['model_objects'] = { 'data_model_version':"DM_2014_10_24_1638" }

# Each container also includes a list
dm['mcell']['geometrical_objects']['object_list'] = []
dm['mcell']['model_objects']['model_object_list'] = []

# Create a transparent surface class
dm['mcell']['define_surface_classes'] = {
  'data_model_version' : "DM_2014_10_24_1638",
  'surface_class_list' : [
    {
      'data_model_version' : "DM_2014_10_24_1638",
      'name' : "transp",
      'surface_class_prop_list' : [
        {
          'affected_mols' : "ALL_MOLECULES",
          'clamp_value' : "0",
          'data_model_version' : "DM_2015_11_08_1756",
          'molecule' : "",
          'name' : "Molec.: ALL_MOLECULES   Orient.: Ignore   Type: Transparent",
          'surf_class_orient' : ";",
          'surf_class_type' : "TRANSPARENT"
        }
      ]
    }
  ]
}

# Define the Modify Surface Regions structure
dm['mcell']['modify_surface_regions'] = {
  'data_model_version' : "DM_2014_10_24_1638",
  'modify_surface_regions_list' : []
}

# Define the count/plot structure
dm['mcell']['reaction_data_output'] = {
  'always_generate' : True,
  'combine_seeds' : True,
  'data_model_version' : "DM_2016_03_15_1800",
  'mol_colors' : False,
  'plot_layout' : " ",
  'plot_legend' : "0",
  'reaction_output_list' : [],
  'rxn_step' : ""
}

# Make a series of transparent icospheres and define a count statement for each one
for i in range(n):
    r = (i+1) * dr
    ico = IcoSphere(ss,r,r,r).make_dm_object ( 0, 0, 0 )
    ico['name'] = 'ico_' + str(i+1)
    ico['material_names'] = [ 'shell_color' ]
    dm['mcell']['geometrical_objects']['object_list'].append ( ico )
    dm['mcell']['model_objects']['model_object_list'].append ( { 'name':ico['name'] } )
    dm['mcell']['modify_surface_regions']['modify_surface_regions_list'].append ( {
              'data_model_version' : "DM_2015_11_06_1732",
              'name' : "Surface Class: transp   Object: ico_%d   ALL" % (i+1),
              'object_name' : "ico_%d" % (i+1),
              'region_name' : "",
              'region_selection' : "ALL",
              'surf_class_name' : "transp"
            } )
    mdl_string = "COUNT[vm,Scene.ico_%d]" % (i+1)
    if i > 0:
        mdl_string += " - COUNT[vm,Scene.ico_%d]" % (i)
    dm['mcell']['reaction_data_output']['reaction_output_list'].append ( {
              'count_location' : "Object",
              'data_file_name' : "",
              'data_model_version' : "DM_2016_03_15_1800",
              'mdl_file_prefix' : "ico_%d" % (i+1),
              'mdl_string' : mdl_string,
              'molecule_name' : "vm",
              'name' : "MDL: Count ico_%d]" % (i+1),
              'object_name' : "ico_%d" % (i+1),
              'plotting_enabled' : True,
              'reaction_name' : "",
              'region_name' : "",
              'rxn_or_mol' : "MDLString"
            } )


# Create a molecule list and create a "vm" molecule along with its display properties in that list
dm['mcell']['define_molecules'] = { 'data_model_version' : "DM_2014_10_24_1638" }
mol = { 'mol_name':"vm", 'mol_type':"3D", 'diffusion_constant':"dc", 'data_model_version':"DM_2016_01_13_1930" }
mol['display'] = {'color':[0.0,1.0,0.0], 'emit':1.0, 'glyph':"Cube", 'scale':0.5 }
dm['mcell']['define_molecules']['molecule_list'] = [ mol ]


# Create a release site
dm['mcell']['release_sites'] = {
  'data_model_version' : "DM_2014_10_24_1638",
  'release_site_list' : [
    {
      'molecule' : "vm",
      'quantity' : "nrel",
      'location_x' : "0",
      'location_y' : "0",
      'location_z' : "0",
      'shape' : "SPHERICAL",
      'site_diameter' : "0",
      'stddev' : "0",
      'name' : "release",
      'object_expr' : "",
      'orient' : ";",
      'pattern' : "",
      'points_list' : [],
      'quantity_type' : "NUMBER_TO_RELEASE",
      'release_probability' : "1",
      'data_model_version' : "DM_2015_11_11_1717"
    }
  ]
}


# Set up the simulation running parameters

dm['mcell']['initialization'] = { 'data_model_version':"DM_2014_10_24_1638" }
dm['mcell']['initialization']['iterations'] = "iters"
dm['mcell']['initialization']['time_step'] = "dt"

dm['mcell']['simulation_control'] = { 'data_model_version': 'DM_2016_04_15_1430' }
dm['mcell']['simulation_control']['start_seed'] = '1'
dm['mcell']['simulation_control']['end_seed'] = 'seeds'


# Return to the previous directory and replace the existing data model with this modified version

cb.cd_to_location ( old_location )
cb.replace_data_model ( dm, geometry=True )

14.1.4.4.2. Initialization

The first part of the script imports the needed modules, gets a copy of the data model, and prints some keys from the data model. This section is pretty self-explanatory. The directory change isn’t needed in this example, because the script doesn’t read or create any files. But it’s included here as good practice.

# Import cellblender to get the data model and project directory functions

import math
import cellblender as cb

# Get a copy of the data model and change directories to the project directory for any file I/O

dm = cb.get_data_model(geometry=True)
old_location = cb.cd_to_project()

# Print some information about the data model

print ( "###############################################################" )

print ( "Data Model Top Level Keys = " + str(dm.keys()) )
print ( "MCell Keys = " + str(dm['mcell'].keys()) )

print ( "###############################################################" )

14.1.4.4.3. Collecting Parameters

The next section of the script uses a common CellBlender scripting idiom for setting and/or obtaining various parameters. The parameters are defined in a Python list of lists. The fields in each list are implied to be the parameter name, value, units, and description. The code then reads through the data model (which may or may not contain these same values in the parameters section) and replaces the defaults with any current values set by the user. If this is the first run of this script in an empty CellBlender model, then none will be found, and the defaults will remain unchanged. Then the script uses these possibly updated values to create local variables that can be used later by the script. It then creates a new data model containing an “mcell” key, and fills its parameter_system dictionary with the possibly updated parameters in the list of lists.

# Define parameters and set default values (these will also be available as local variables in this script)
#  The format for each parameter is:   Name, Value, Units, Description
#    All values are given as strings!!!

pars = [
  # These control the geometry of the model
  ['n',    "3",       '#',   'Number of shells to sample'],
  ['dr',   "0.1",    'um',   'Delta Radius of each successive shell'],
  ['ss',   "2",       '#',   'Surface Smoothness of each shell'],
  # These describe the behavior of the model
  ['dc',    "1e-6",   'cm^2/sec',    'Diffusion Constant of Molecules'],
  ['nrel',  "1000",   'Count',       'Number of molecules to release'],
  # These control the simulation itself
  ['iters', "600",   '',      'Number of iterations to run'],
  ['seeds', "1",     '',      'Number of seeds to run'],
  ['dt',    "1e-6",  'sec',   'Time step for each iteration of the simulation'],
 ]

# Update local parameter list values from the existing data model with user-modified settings BEFORE regenerating it
dm_par_list = dm['mcell']['parameter_system']['model_parameters']
for dm_par in dm_par_list:
    print ( "Data Model Parameter " + dm_par['par_name'] + " = " + dm_par['par_expression'] )
    for p in pars:
        if dm_par['par_name'] == p[0]:
            # Update the local expression based on the parameter found in the incoming data model
            p[1] = dm_par['par_expression']
            p[2] = dm_par['par_units']
            p[3] = dm_par['par_description']

# Create the local variables from the updated values to use in this script
for p in pars:
    locals()[p[0]] = eval(p[1])

# Create the new mcell data model inside the existing data model (this deletes the previous mcell data model)
dm['mcell'] = { 'data_model_version' : "DM_2014_10_24_1638" }


# Restore the parameters that were either initialized from scratch or preserved from the previous data model
dm['mcell']['parameter_system'] = { 'model_parameters':[] }   # Parameters are currently unversioned
for p in pars:
    dm['mcell']['parameter_system']['model_parameters'].append ( { 'par_name':p[0], 'par_expression':p[1], 'par_units':p[2], 'par_description':p[3] } )

14.1.4.4.4. Defining Geometry Support Classes

This next section is probably the most model-specific portion of the script. It generates the geometrical objects needed for the model. In some cases, this geometrical data can simply be read from a file. In other cases, it can use some of Blender’s internal mesh functions. In still other cases, it might just assume that the proper geometrical objects have already been created.

Creating mesh objects from scratch can be somewhat tedious. For this model, we’ll need a series of concentric spheres for counting. It turns out the Blender has a built-in function that could create these spheres (or more properly, icospheres) for us. But that’s certainly not the case for all geometrical objects. So this code shows how it can be done from scratch. This entire section is written to support a simple call to make an icosphere:

ico = IcoSphere(ss,r,r,r).make_dm_object ( 0, 0, 0 )

The result should be a dictionary of points and faces representing the icosphere in data model format. This particular example starts by building an icosahedron with 12 points and 20 faces. The algorithm then recursively subdivides each face into 4 smaller faces. The new points are then renormalized to be on the sphere and the process is repeated until the desired number of subdivisions has been reached.

The algorithm uses its own internal representation of points and faces (the point and face classes). Eventually it calls the “make_dm_object” to convert that internal representation into a CellBlender data model compatible dictionary named “obj” that it returns.

##################################
#   Geometry  Support  Classes   #
##################################

class point:

  def __init__ ( self, x, y, z ):
    self.x = x;
    self.y = y;
    self.z = z;


class face:

  def __init__ ( self, v1, v2, v3 ):
    self.verts = [];
    self.verts.append ( v1 );
    self.verts.append ( v2 );
    self.verts.append ( v3 );


class IcoSphere:

  # Builds an icosphere with recursion

  def __init__ ( self ):
    self.points = []
    self.faces = []

  def make_dm_object ( self, center_x=0, center_y=0, center_z=0 ):
    obj = {}
    obj['vertex_list'] = []
    obj['element_connections'] = []

    for p in self.points:
      obj['vertex_list'].append ( [ center_x+p.x, center_y+p.y, center_z+p.z ] )
    for f in self.faces:
      obj['element_connections'].append ( f.verts )

    return obj

  def add_normalized_vertex ( self, p ):
    # Normalize the point
    # Add to the list of points if it's not already in the list
    # Return an index to the new or existing point in the list

    l = math.sqrt ( (p.x * p.x) + (p.y * p.y) + (p.z * p.z) );
    pnorm = point ( p.x/l, p.y/l, p.z/l );

    # Check if it's already there
    index = -1;
    for pt in self.points:
      if (pt.x == pnorm.x) and (pt.y == pnorm.y) and (pt.z == pnorm.z):
        index = self.points.index(pt)
        break;

    if (index < 0):
      self.points.append ( pnorm );
      index = self.points.index ( pnorm );
      #print ( "Added vertex at " + str(index) );
    #else:
    #  print ( "Found vertex at " + str(index) );
    return (index);


  def __init__ ( self, recursion_level, scale_x=1.0, scale_y=1.0, scale_z=1.0 ):

    self.points = [];

    t = (1.0 + math.sqrt(5.0)) / 2.0;  # Approx 1.618033988749895

    # Create 12 verticies from the 3 perpendicular planes whose corners define an icosahedron

    self.add_normalized_vertex ( point (-1,  t,  0) );
    self.add_normalized_vertex ( point ( 1,  t,  0) );
    self.add_normalized_vertex ( point (-1, -t,  0) );
    self.add_normalized_vertex ( point ( 1, -t,  0) );

    self.add_normalized_vertex ( point ( 0, -1,  t) );
    self.add_normalized_vertex ( point ( 0,  1,  t) );
    self.add_normalized_vertex ( point ( 0, -1, -t) );
    self.add_normalized_vertex ( point ( 0,  1, -t) );

    self.add_normalized_vertex ( point ( t,  0, -1) );
    self.add_normalized_vertex ( point ( t,  0,  1) );
    self.add_normalized_vertex ( point (-t,  0, -1) );
    self.add_normalized_vertex ( point (-t,  0,  1) );


    # Rotate all points such that the resulting icosphere will be separable at the equator

    if (True):
      # A PI/6 rotation about z (transform x and y) gives an approximate equator in x-y plane
      angle = (math.pi / 2) - math.atan(1/t);
      # print ( "Rotating with angle = " + str(180 * angle / math.pi) );
      for p in self.points:
        newx = (math.cos(angle) * p.x) - (math.sin(angle) * p.z);
        newz = (math.sin(angle) * p.x) + (math.cos(angle) * p.z);
        p.x = newx;
        p.z = newz;

    # Build the original 20 faces for the Icosphere

    self.faces = []

    # Add 5 faces around point 0 (top)
    self.faces.append ( face (  0, 11,  5 ) );
    self.faces.append ( face (  0,  5,  1 ) );
    self.faces.append ( face (  0,  1,  7 ) );
    self.faces.append ( face (  0,  7, 10 ) );
    self.faces.append ( face (  0, 10, 11 ) );

    # Add 5 faces adjacent faces
    self.faces.append ( face (  1,  5,  9 ) );
    self.faces.append ( face (  5, 11,  4 ) );
    self.faces.append ( face ( 11, 10,  2 ) );
    self.faces.append ( face ( 10,  7,  6 ) );
    self.faces.append ( face (  7,  1,  8 ) );

    # Add 5 faces around point 3 (bottom)
    self.faces.append ( face (  3,  9,  4 ) );
    self.faces.append ( face (  3,  4,  2 ) );
    self.faces.append ( face (  3,  2,  6 ) );
    self.faces.append ( face (  3,  6,  8 ) );
    self.faces.append ( face (  3,  8,  9 ) );

    # Add 5 faces adjacent faces
    self.faces.append ( face (  4,  9,  5 ) );
    self.faces.append ( face (  2,  4, 11 ) );
    self.faces.append ( face (  6,  2, 10 ) );
    self.faces.append ( face (  8,  6,  7 ) );
    self.faces.append ( face (  9,  8,  1 ) );


    # Subdivide the faces as requested by the recursion_level argument
    old_points = None;
    old_faces = None;

    for rlevel in range(recursion_level):
      # System.out.println ( "\nRecursion Level = " + rlevel );
      # Save the old points and faces and build a new set for this recursion level
      old_points = self.points;
      old_faces = self.faces;
      self.points = []
      self.faces = []
      for f in old_faces:
        # Split this face into 4 more faces
        midpoint = point(0,0,0)
        potential_new_points = []
        for i in range(6):
          potential_new_points.append ( point(0,0,0) )
        for side in range(3):
          p1 = old_points[f.verts[side]];
          p2 = old_points[f.verts[(side+1)%3]];
          midpoint = point ( ((p1.x+p2.x)/2), ((p1.y+p2.y)/2), ((p1.z+p2.z)/2) );
          potential_new_points[2*side] = p1;
          potential_new_points[(2*side)+1] = midpoint;
        # Add the 4 new faces
        # Start with the verticies ... add them all since add_normalized_vertex() will remove duplicates
        vertex_indicies = []
        for i in range(6):
          vertex_indicies.append ( 0 )
        for i in range(6):
          vertex_indicies[i] = self.add_normalized_vertex ( potential_new_points[i] );
        # Now add the 4 new faces
        self.faces.append ( face ( vertex_indicies[0], vertex_indicies[1], vertex_indicies[5] ) );
        self.faces.append ( face ( vertex_indicies[1], vertex_indicies[2], vertex_indicies[3] ) );
        self.faces.append ( face ( vertex_indicies[3], vertex_indicies[4], vertex_indicies[5] ) );
        self.faces.append ( face ( vertex_indicies[1], vertex_indicies[3], vertex_indicies[5] ) );

    for pt in self.points:
      pt.x *= scale_x
      pt.y *= scale_y
      pt.z *= scale_z

14.1.4.4.5. Creating Materials, Containers, and a Transparent Surface Class

Building a data model is mostly making dictionaries and lists with CellBlender’s expected keys. In this next section of code, new dictionaries are made for materials, geometrical objects, and model objects. These will all be filled by looping in subsequent sections of this script. Since a transparent surface class will be needed, it’s created here as well. Note the pattern of setting up empty lists that will be filled in later.

# Add materials for the objects
dm['mcell']['materials'] = { 'material_dict' : {} }   # Materials are currently unversioned
dm['mcell']['materials']['material_dict']['shell_color']   = { 'diffuse_color' : {'a':0.3, 'r':0.2, 'g':0.4, 'b':1.0} }


# Create container objects for geometrical objects and model objects
dm['mcell']['geometrical_objects'] = {}   # Geometrical objects are currently unversioned
dm['mcell']['model_objects'] = { 'data_model_version':"DM_2014_10_24_1638" }

# Each container also includes a list
dm['mcell']['geometrical_objects']['object_list'] = []
dm['mcell']['model_objects']['model_object_list'] = []

# Create a transparent surface class
dm['mcell']['define_surface_classes'] = {
  'data_model_version' : "DM_2014_10_24_1638",
  'surface_class_list' : [
    {
      'data_model_version' : "DM_2014_10_24_1638",
      'name' : "transp",
      'surface_class_prop_list' : [
        {
          'affected_mols' : "ALL_MOLECULES",
          'clamp_value' : "0",
          'data_model_version' : "DM_2015_11_08_1756",
          'molecule' : "",
          'name' : "Molec.: ALL_MOLECULES   Orient.: Ignore   Type: Transparent",
          'surf_class_orient' : ";",
          'surf_class_type' : "TRANSPARENT"
        }
      ]
    }
  ]
}

14.1.4.4.6. Building Containers for Surface Regions and Counting

The model will also need to modify surface regions to make them transparent and it will need to generate count statements. Again, the empty list structures are created to be filled in later.

# Define the Modify Surface Regions structure
dm['mcell']['modify_surface_regions'] = {
  'data_model_version' : "DM_2014_10_24_1638",
  'modify_surface_regions_list' : []
}

# Define the count/plot structure
dm['mcell']['reaction_data_output'] = {
  'always_generate' : True,
  'combine_seeds' : True,
  'data_model_version' : "DM_2016_03_15_1800",
  'mol_colors' : False,
  'plot_layout' : " ",
  'plot_legend' : "0",
  'reaction_output_list' : [],
  'rxn_step' : ""
}

14.1.4.4.7. Looping to build Geometrical Objects, assign Surface Classes, and make Count Statements

Now that all of the empty “containers” have been set up, this section of code can loop through the requested number of measuring shells and do the following things:

  • Create the geometry (icosphere) for each shell

  • Name each icosphere

  • Assign a material to each icosphere

  • Append each icosphere to the geometrical objects list and the model objects list

  • Apply a surface region modification to make each icosphere transparent to all molecules

  • Create a Count statement for each icosphere that subtracts the count of the previous (inner) icosphere

That’s a lot of tasks, but they’re easily accomplished because everything has already been set up.

# Make a series of transparent icospheres and define a count statement for each one
for i in range(n):
    r = (i+1) * dr
    ico = IcoSphere(ss,r,r,r).make_dm_object ( 0, 0, 0 )
    ico['name'] = 'ico_' + str(i+1)
    ico['material_names'] = [ 'shell_color' ]
    dm['mcell']['geometrical_objects']['object_list'].append ( ico )
    dm['mcell']['model_objects']['model_object_list'].append ( { 'name':ico['name'] } )
    dm['mcell']['modify_surface_regions']['modify_surface_regions_list'].append ( {
              'data_model_version' : "DM_2015_11_06_1732",
              'name' : "Surface Class: transp   Object: ico_%d   ALL" % (i+1),
              'object_name' : "ico_%d" % (i+1),
              'region_name' : "",
              'region_selection' : "ALL",
              'surf_class_name' : "transp"
            } )
    mdl_string = "COUNT[vm,Scene.ico_%d]" % (i+1)
    if i > 0:
        mdl_string += " - COUNT[vm,Scene.ico_%d]" % (i)
    dm['mcell']['reaction_data_output']['reaction_output_list'].append ( {
              'count_location' : "Object",
              'data_file_name' : "",
              'data_model_version' : "DM_2016_03_15_1800",
              'mdl_file_prefix' : "ico_%d" % (i+1),
              'mdl_string' : mdl_string,
              'molecule_name' : "vm",
              'name' : "MDL: Count ico_%d]" % (i+1),
              'object_name' : "ico_%d" % (i+1),
              'plotting_enabled' : True,
              'reaction_name' : "",
              'region_name' : "",
              'rxn_or_mol' : "MDLString"
            } )

14.1.4.4.8. Defining Molecules and a Release Site

Since this model only has one molecule and one release site, these can be created directly.

# Create a molecule list and create a "vm" molecule along with its display properties in that list
dm['mcell']['define_molecules'] = { 'data_model_version' : "DM_2014_10_24_1638" }
mol = { 'mol_name':"vm", 'mol_type':"3D", 'diffusion_constant':"dc", 'data_model_version':"DM_2016_01_13_1930" }
mol['display'] = {'color':[0.0,1.0,0.0], 'emit':1.0, 'glyph':"Cube", 'scale':0.5 }
dm['mcell']['define_molecules']['molecule_list'] = [ mol ]


# Create a release site
dm['mcell']['release_sites'] = {
  'data_model_version' : "DM_2014_10_24_1638",
  'release_site_list' : [
    {
      'molecule' : "vm",
      'quantity' : "nrel",
      'location_x' : "0",
      'location_y' : "0",
      'location_z' : "0",
      'shape' : "SPHERICAL",
      'site_diameter' : "0",
      'stddev' : "0",
      'name' : "release",
      'object_expr' : "",
      'orient' : ";",
      'pattern' : "",
      'points_list' : [],
      'quantity_type' : "NUMBER_TO_RELEASE",
      'release_probability' : "1",
      'data_model_version' : "DM_2015_11_11_1717"
    }
  ]
}

14.1.4.4.9. Defining Simulation Run Parameters and Replacing the Data Model

The final step is setting up the initialization and run control sections. Note that the parameters “iters” and “dt” and “seeds” are given as string expressions. These refer to the parameters that have already been added to the data model. This will allow these to be changed easily from the parameter panel each time the simulation is re-run.

The last two calls restore the default directory location to the location saved at the top of this script and replace the CellBlender data model with the data model that we built in this script. Once that last call has returned, all of CellBlender’s properties will have been replaced with values from the data model that we built in this script.

# Set up the simulation running parameters

dm['mcell']['initialization'] = { 'data_model_version':"DM_2014_10_24_1638" }
dm['mcell']['initialization']['iterations'] = "iters"
dm['mcell']['initialization']['time_step'] = "dt"

dm['mcell']['simulation_control'] = { 'data_model_version': 'DM_2016_04_15_1430' }
dm['mcell']['simulation_control']['start_seed'] = '1'
dm['mcell']['simulation_control']['end_seed'] = 'seeds'


# Return to the previous directory and replace the existing data model with this modified version

cb.cd_to_location ( old_location )
cb.replace_data_model ( dm, geometry=True )
